Mnt. pesenan:1 Piece/Pieces
Model No.: BA104S01-100
Ba104s01-100 mangrupikeun produk modul 10.4-in44 inci (Boe) nganggo téknologi A-SIP-LCT-LCD. Hal ieu dilengkepan bosen, teu aya tukang nyetir sareng teu toél. Ba104S01-100 nunjukkeun resolusi 800 (RGB) × 600 (SVGA), rasio Aspék 4: 3 (Jangkungna. .1 dileupaskeun ku Bu dina 12 Désémber 2014. Ukuran wewengkon tampilan nyaéta 211.2 × 158.0 ° (Tampilan × 161.9 (lebar × × 162.9 (lebar × ° ×9 (ketebalan) mm, perawatan permukaan jelas, beurat net net mangrupikeun 288g (ngetik.). Sabalikna produk ieu nganggo sumber lampu éditor 6S6p gentos (luhur), kahirupan sumber cahya nyaéta 50k jam, teu aya lampu tukang. Ba104S0-1-100 baloko LVD (1 CH, 6/K) antarbeungir bitér, sajumlah paningkatan nu tyal, toko terminar mangrupikeun 3.3V.). Refresh anu tipisk anu khas na fv nyaéta 60hz. Ngoperasikeun di -20 ° C kana 70 ° C sareng toko tabuh -30 c kanggo 80 ° C. Modél ieu disarankeun pikeun dianggo dina imaging industri sareng médis alami api bodas na - leuwih ti 50,000 jam hirup, 4- Prilfér téral.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Ieu mangrupikeun modél ukuran anu sami sareng parameter
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
