Model No.: MT220WPM-N10
| Panel Brand | BOE | Panel Model | MT220WPM-N10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 250nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Touch Screen | Without |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Input Voltage | 5.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
Mt220wPM-N10, layar modul 22-inci 22-inci, resolusi pintonan nyaéta 1650 * 1050, rasio aspék: 16:10 (lebar: jangkungna)
Wewengkon: 473.76 (W) × 296.1 (H) mm
Daérah katingali: 477.7 (W) × 300.1 (H) mm
Diménsi: 493.7 (W) × 320.1 (H) × 10,7 (d) mm
Sumber lampu cahya, HOM rambuts pikeun sumber cahaya nyaéta rata-jam, sareng tingkat refreshed nangtung nyaéta 60hz.
Suhu operasi: 0 ~ 50 ° C
Suhu neundeun: -25 ~ 60 ° C
Aplikasi: Cocog kanggo monitor komputer.
Tag Panas: Mt220WPM-N10 22.0 "1000nit Panel LcD LCD LCD LCD LCD LCD LCD, pabrik, transmisasi LCD, 2000 NFR Tampilan, layar SEMI luar
21.5 Inci Roundsor Sun Senén anu tiasa dibaca Panel LCD anu tiasa dibaca
12.1 "1000nit luar TFT layar témbal layar LCD
